GlobalFood/oil resistant
HYBRID TOYOFOODS HOSE
Model | HTF
Features
-
Kink- and collapse-resistant hoses for improved transport efficiency
-
With a small bending radius useful for piping in tight spaces
-
Long-lasting
Download materials
Product features
-
Kink- and collapse-resistant hoses for improved transport efficiency
Good shape retention so fluids are not stopped during conveyance, preventing production problems
Kink- and collapse-resistant hoses for improved transport efficiency
Good shape retention so fluids are not stopped during conveyance, preventing production problems
-
With a small bending radius useful for piping in tight spaces
It does not easily kink or collapse, so it can be used in narrow spaces and is suitable for moving parts.
With a small bending radius useful for piping in tight spaces
It does not easily kink or collapse, so it can be used in narrow spaces and is suitable for moving parts.
-
Long-lasting
High oil resistance and long service life, even when used with oily and fatty foods
* Can also be used with mineral oil
Long-lasting
High oil resistance and long service life, even when used with oily and fatty foods
* Can also be used with mineral oil -
Compliant with various laws and regulations regarding safety and security
Compliant with Food Sanitation Act (Compliant with Notice of the Ministry of Health, Labour and Welfare No. 196, 2020 “PL System”)
Compliant with corrected RoHS 2 regulations
Compliant with various laws and regulations regarding safety and security
Compliant with Food Sanitation Act (Compliant with Notice of the Ministry of Health, Labour and Welfare No. 196, 2020 “PL System”)
Compliant with corrected RoHS 2 regulations
HYBRID TOYOFOODS HOSE
Food/oil resistant
| Application | For delivering foods, beverages, water and more | |
|---|---|---|
| Fluid | ||
| Function |
Positive pressure (pressure feed) Negative pressure (vacuum) High-pressure-resistant Heat-resistant Cold-resistant Transparent Flexible Kinking/collapse prevention Oil-resistant (animal/vegetable oil) Oil-resistant (mineral oil) Chemical-resistant Low odor Low elution Non-adhesive Antistatic Dew condensation prevention Abrasion-resistant Flame retardant Plasticizer-free Disposal sorting not required |
|
| Regulatory | Food Sanitation Act No. 196 compliant RoHS 2 compliant | |
| Specification | Main material | Soft PVC |
| Reinforcing material | Specialized PET resin / Polyester thread | |
| Inner diameter | 15mm~25mm | |
| Operating temperature range | -5℃~70℃ | |
| Other | ||
Specifications table by size Operating temperature range -5℃ 〜 70℃
| Model | Inner diameter × Outer diameter (mm) | Operating pressure (MPa) | Standard weight (kg/roll) | Standard length (m) | Minimum bending radius (mm) |
|---|---|---|---|---|---|
| HTF-15 | 15 × 22 | 0~0.8 | 25 | 100 | 70 |
| HTF-19 | 19 × 26 | 0~0.6 | 16 | 50 | 90 |
| HTF-25 | 25 × 33 | 0~0.6 | 24 | 50 | 120 |
Packing: bobbin style Coloring: natural clear, green line added
Related links
Compatible Couplings
| Hose details | Hose connection | Cap nut | Cap nut | Cap nut | Cap nut | Cap nut | Cap nut | Cap nut | Cap nut | Cap nut | Crimped |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Coupling specifications | Male thread | Male thread | Ferrule | Ferrule | Male thread | Male thread | Male thread | Male thread | Coupler | Ferrule | |
| Main material |
Brass
|
Brass
|
Stainless steel
|
Stainless steel
|
Brass + resin
|
Resin (PPSU)
|
Stainless steel
|
Stainless steel
|
Stainless steel
|
Stainless steel
|
|
| Model No. | TC2-B | TC3-B | TC3-F | TC3-FG | TC3-PB | TC3-PC | TC3-S | TC2-S | TC3-CS | HFA | |
| Hose model |
Inner
diameter (mm) Outer
diameter (mm) |
|
|
|
|
|
|
|
|
|
|
| HTF-15 |
15
22
|
◯ | ◯ | ◯ | ◯ | ◯ | ◯ | ◯ | ◯ | - | - |
| HTF-19 |
19
26
|
◯ | ◯ | ◯ | ◯ | ◯ | ◯ | ◯ | ◯ | ◯ | - |
| HTF-25 |
25
33
|
◯ | ◯ | ◯ | ◯ | ◯ | ◯ | ◯ | ◯ | ◯ | ◯ |
Compatible KAMLOK
| Hose details | Hose connection | Hose clamp tightening | Hose clamp tightening | Hose clamp tightening | Hose clamp tightening | Hose clamp tightening | Hose clamp tightening | Hose clamp tightening | Hose clamp tightening | Cap nut | Hose clamp tightening |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Coupling specifications | Coupler | Coupler | Coupler | Coupler | Coupler | Adapter | Adapter | Adapter | Coupler | Coupler | |
| Main material |
Aluminum alloy
|
Resin (PP)
|
Stainless steel
|
Aluminum alloy
|
Stainless steel
|
Aluminum alloy
|
Resin (PP)
|
Stainless steel
|
Stainless steel
|
Resin (PP)
|
|
| Model No. | 633-C-AL | 633-C-PP | 633-C-SST | 633-CL-AL | 633-CL-SST | 633-E-AL | 633-E-PP | 633-E-SST | TC3-CS | 633-CL-PP | |
| Hose model |
Inner
diameter (mm) Outer
diameter (mm) |
 |
 |
 |
 |
 |
 |
 |
 |
|
 |
| HTF-15 |
15
22
|
- | - | - | - | - | - | - | - | - | - |
| HTF-19 |
19
26
|
◯ | ◯ | ◯ | ◯ | ◯ | ◯ | ◯ | ◯ | ◯ | - |
| HTF-25 |
25
33
|
◯ | ◯ | ◯ | ◯ | ◯ | ◯ | ◯ | ◯ | ◯ | ◯ |
